Implementing Versioning and Audit Trails with SQL Server Temporal Tables and .Net Core

By Ross Jones

Inevitably, when building enterprise software, you will be required to implement audit trail and versioning functionality. At its core, versioning and audit trails rely on point-in-time snapshots, which my team and I recently investigated different ways to implement. We opted for a solution built with ASP.NET Core and SQL Server Temporal Tables. Here’s why, and how we implemented it.

ross_jones_articleimage_1

What we needed to build

I work as a developer for a South African insurance company called OUTsurance. Since protecting sensitive personal data and preventing fraud are such key concerns to my company, our core insurance system needed reliable auditing. When data is changed, we need to be able to see:

  • Who made the change,
  • What was changed,
  • When it was changed, and
  • Why it was changed.

An audit trail is a record of change to your data which serves as proof of compliance with the application’s business rules. It can be used to assist with identifying problems in your software and spotting fraudulent transactions among other things.

In addition, we need a mechanism to version the data so that we can support complex business processes which rely on the data at specific points in time.

Versioning involves assigning a version number to your data at a specific point in time. This allows data to be changed without breaking business processes which rely on earlier versions of the data.

For this article, let’s look at a simplified example of what my team needed to build. Our sample system will keep a registry of customers, along with a list of addresses for properties that they need to insure.


+----------+         +----------+

|          |         |          |

| Customer + ----->> + Address  |

|          |         |          |

+----------+         +----------+

For security purposes, any change to a customer or an associated address must be audited. Additionally, for any given change, the full state of the customer at that point in time must be retrievable via a REST API call which is to be consumed by a front-end or another service. A change to a customer would mean any of the following:

  • A property on the customer is changed
  • An address is added or removed
  • A property on an address is changed

Separately, to support business processes which rely on data at a specific point in time, we should also be able to create a version of a customer that can be retrieved via a REST API using the version number.

Why it was difficult to do this

The technical solution required for implementing point-in-time snapshots is complex and requires a lot of time and experience to implement well.

  • If your implementation is too fine-grained: You will land up with a complex technical solution where your code is polluted with details associated with tracking changes on individual properties. Just like the infamous INotifyPropertyChanged interface.
  • If your implementation is too coarse: You risk sacrificing system efficiency. For example, you may be tempted to just serialise your entire object graph and store that as a JSON dump for every change that is made.

Since it is difficult, and is often seen as a non-functional requirement, we defer the implementation of these requirements until it is too late. The result is that we land up with a very technical solution which lacks the rich behaviour that the business requires. In the worst case, we use the output of development logging tools as an audit trail… You should be ashamed of yourselves! :D

Our options — and why we picked SQL Server Temporal Tables

There are two solutions to the point-in-time snapshots problem which require a mention.

  1. Snapshot Memento: An obvious solution would be to take a snapshot of the application state before a change is applied. If implemented naively, the snapshots become large and impractical to work with. An obvious optimisation of this would be to create a snapshot for only the portion of the application state which has changed. This is how git works under the hood. Rolling a custom solution to achieve this can be challenging, and we decided it should be left to the storage infrastructure to solve. This ensures that our domain logic remains pure and free from unnecessary complexity.
  2. Event Sourcing: Event Sourcing is an approach to storing the application state as a series of events. The state is then restored by replaying events in the order that they occurred to materialise the latest state. To restore data to a specific point-in-time, you replay the events up to the time that you need. Event sourcing requires a big shift in the way applications are built, since events are at the core of the business data model. While this is a very powerful and relevant solution for some domains, the fact is that it introduces complexity which felt unnecessary for our requirements. Typically, solutions like this will work best with purpose-built infrastructure components such as EventStore.

We will implement a snapshot solution using SQL temporal tables. It is a great point-in-time snapshot implementation, which we can leverage with relatively little effort - but it does require some upfront design. It uses snapshots at the row level so, when a row is updated, a snapshot of the row is copied over to the associated history table. The benefit of this is that it gives us snapshot granularity at the row level.

This was the best option for us since the technical challenges of doing it are hidden away and exposed via a few additional SQL statements - which makes it very simple to work with.

How we implemented SQL server temporal tables

While it would be possible to turn on the temporal tables and call it a day, there are some concepts which must be understood for auditing and versioning to be first-class citizens of our business domain. This means using Domain Driven Design and implementing a Command Query Responsibility Segregation pattern which would help us to:

  • Unlock the rich functionality required within this domain, and
  • Achieve an appropriate separation of concerns within the implementation.

Command Query Responsibility Segregation:

In the sample system, we will be using the Command Query Responsibility Segregation CQRS pattern. While the term is a mouthful, the concept is simple. It means that our system will be split into two separate software models:

  • The write side for commands: We will build a model backed by SQL tables using Entity Framework Core There will be no need to utilise temporal table features directly in this layer since we will be using plain old Entity Framework.
  • The read side for queries: This is another set of classes which will be used for reads. This model will be built over SQL views using Dapper. This layer will be doing the heavy lifting with some help from the temporal tables.

Domain Driven Design

Domain Driven Design DDD is essentially a way of thinking about the design of your system. It provides strategic and tactical patterns which you can use to build a software domain model. A full explanation is outside the scope of this post, however we need to understand the concept of an aggregate which will help us solve the versioning and auditing problem.

A DDD aggregate is a cluster of domain objects that can be treated as a single unit. An example would be an order and its line-items. These will be separate objects, but it’s useful to treat the order and its line items as a single aggregate.

In our sample system, we have one aggregate which is the customer. The DDD concept of an aggregate is important in this context because we will be versioning and auditing it. So, if any object within the aggregate changes or a new version is created, a snapshot will be created for the whole aggregate.

Step 1: The write model

I have set up the write model using Entity Framework Core. This is well documented here and I won’t go into details on this.

Since the customer is an aggregate, it can control its invariants via behaviour methods, like AddAddress, UpdateAddress etc. This is what gives us the hook to create a contextual audit record.

When a behaviour method is called on the aggregate, it creates an Audit with a meaningful message like “Address added” or “Address updated”. Since multiple changes could occur in a single transaction, or unit of work, a single audit can contain multiple messages. This is analogous to a GIT commit.

The audit is persisted with a Timestamp which we will use to query the temporal tables and retrieve a snapshot of the aggregate at that point in time.

Since we have used DDD to model our domain objects, we have an Audit object which is used to reliably recall a list of changes for a given aggregate, as well as view those changes in a readable way for humans. If we need to view the state of the aggregate at that point in time, we can retrieve that snapshot of the aggregate using an audit ID.

The exact same mechanism is used for versions. Of course, the subtle difference is that creating a new version requires an explicit call to IncrementVersion by user code. This is analogous to creating a GIT tag or release.

As a result, we have an audit and a version as a first-class concept within our domain model. This is represented by the Audit and Version classes, which are not bogged down with any point-in-time snapshot technical complexity.

In code, our domain model appears as follows:

public class Customer

{

    private Audit _currentAudit;

    private readonly List<Address> _addresses;

    private readonly List<Audit> _audits;

    private readonly List<Version> _versions;

    internal Customer()

    {

        _addresses = new List<Address>();

        _audits = new List<Audit>();

        _versions = new List<Version>();

    }

    public Customer(string name) : this()

    {

        Name = name;

        OnChanged("Customer created");

    }

    public int Id { get; private set; }

    public string Name { get; private set; }

    public IReadOnlyCollection<Address> Addresses => _addresses;

    public IReadOnlyCollection<Audit> Audits => _audits;

    public IReadOnlyCollection<Version> Versions => _versions;



    public void Update(string name)

    {

        Name = name;

        OnChanged("Name changed");

    }

    public Address AddAddress(

        string line,

        string suburb,

        string city,

        string province,

        string code)

    {

        var address = new Address(

            customer: this,

            line: line,

            suburb: suburb,

            city: city,

            province: province,

            code: code);

        _addresses.Add(address);

        OnChanged("Address added");

        return address;

    }

    public void UpdateAddress(int addressId,

        string line,

        string suburb,

        string city,

        string province,

        string code)

    {

        var address = _addresses.Single(a => a.Id == addressId);

        address.Update(

            line: line,

            suburb: suburb,

            city: city,

            province: province,

            code: code);

        OnChanged($"Address {addressId} updated");

    }

    public void IncrementVersion(string message)

    {

        var version = new Version(

            message: message);

        _versions.Add(version);

    }

    private void OnChanged(string message)

    {

        if (_currentAudit == null)

        {

            _currentAudit = new Audit();

            _audits.Add(_currentAudit);

        }

        _currentAudit.AddMessage(message);

    }

}
public class Address

{

    public Address(Customer customer,

        string line,

        string suburb,

        string city,

        string province,

        string code) : this()

    {

        Customer = customer;

        Line = line;

        Suburb = suburb;

        City = city;

        Province = province;

        Code = code;

    }

    public int Id { get; private set; }

    public Customer Customer { get; private set; }

    public string Line { get; private set; }

    public string Suburb { get; private set; }

    public string City { get; private set; }

    public string Province { get; private set; }

    public string Code { get; private set; }

    internal void Update(

        string line,

        string suburb,

        string city,

        string province,

        string code)

    {

        Line = line;

        Suburb = suburb;

        City = city;

        Province = province;

        Code = code;

    }

}
public class Audit

{

    private List<string> _messages;

    internal Audit()

    {

        _messages = new List<string>();

    }

    public DateTime Timestamp { get; private set; }

    public IReadOnlyCollection<string> Messages => _messages;

    internal void AddMessage(string message)

    {

        _messages.Add(message);

    }

}
public class Version

{

    internal Version(string message) : this()

    {

        Message = message;

    }

    public string Message { get; set; }

    public DateTime Timestamp { get; private set; }

}

Step 2: Configuring SQL temporal tables

Up to this point, we have done nothing out of the ordinary, and have only used vanilla Entity Framework Core. The magic comes in with the SQL temporal tables.

The tables behind the domain objects described above have been set up in a specific way to make use of the SQL temporal table feature. The guidance on setting this up is well documented here.

The gist is that you will need to create an associated history table for each table that you want to track for changes. When a value within a row changes, the old row is moved into the history table and the update is applied to the row in the main table.

Our aggregate is made up of a number of entities but, when a change is made, SQL Server will only take a snapshot of the rows which have changed, which prevents wasted disk space. When joining together a number of tables, SQL Server will take care of selecting the correct version of the data from each table for the specified point in time.

You will need to be careful about what data you store in a given column. If you are storing huge JSON blobs in a column, then you will land up wasting disk space since that entire column will be moved into the history table.

For example, the address history table is created with the following SQL command:

CREATE TABLE [dbo].[AddressHistory]

(

  [Id] INT NOT NULL,

  [Line] NVARCHAR(255) NOT NULL,

  [Suburb] NVARCHAR(255) NOT NULL,

  [City] NVARCHAR(255) NOT NULL,

  [Province] NVARCHAR(255) NOT NULL,

  [Code] NVARCHAR(255) NOT NULL,

  [CustomerId] INT NOT NULL,

  [SysStartTime] DATETIME2 NOT NULL,

  [SysEndTime] DATETIME2 NOT NULL

)

GO

CREATE CLUSTERED COLUMNSTORE INDEX IX_AddressHistory ON [dbo].[AddressHistory];

GO

CREATE NONCLUSTERED INDEX IX_AddressHistory_ID_PERIOD_COLUMNS ON [dbo].[AddressHistory] ([SysEndTime], [SysStartTime], [Id]);

GO

And the main address table is created as follows:

CREATE TABLE [dbo].[Address]

(

  [Id] INT NOT NULL PRIMARY KEY IDENTITY,

  [Line] NVARCHAR(255) NOT NULL,

  [Suburb] NVARCHAR(255) NOT NULL,

  [City] NVARCHAR(255) NOT NULL,

  [Province] NVARCHAR(255) NOT NULL,

  [Code] NVARCHAR(255) NOT NULL,

  [CustomerId] INT NOT NULL,

  [SysStartTime] DATETIME2 GENERATED ALWAYS AS ROW START NOT NULL,

  [SysEndTime] DATETIME2 GENERATED ALWAYS AS ROW END NOT NULL,

  CONSTRAINT [FK_Address_Customer] FOREIGN KEY ([CustomerId]) REFERENCES [Customer]([Id]),

  PERIOD FOR SYSTEM_TIME ([SysStartTime], [SysEndTime])

)

WITH (SYSTEM_VERSIONING = ON (HISTORY_TABLE = [dbo].[AddressHistory]))

Step 3: The read model

Now that we have set up the write model along with the tables to store our aggregate, we will take a look at the read model. We will create an abstraction between our write model and read model using a SQL view, which will help keep our SQL queries clean and simple.

When querying a view with the FOR keyword, SQL will apply the temporal query to all the tables which are referenced inside of the view. If we do not use a view, we would need to specify the FOR keyword on each table referenced in the query - which would be error prone and ugly.

The SQL command to create the view would appear as follows:

Note how there is no reference to the SQL temporal tables feature yet, that will come when we write our query against the view.

CREATE VIEW [dbo].[v_Customer] AS

SELECT

    [Id],

    [Name],

    JSON_QUERY((

      SELECT

      [Address].[Id],

      [Address].[Line],

      [Address].[Suburb],

      [Address].[City],

      [Address].[Province],

      [Address].[Code]

      FROM

          [Address]

      WHERE

          [Address].[CustomerId] = [Customer].[Id]

      FOR JSON PATH

    )) AS [Addresses]

FROM

    [Customer]

The SQL query to retrieve the customer for a specific audit would appear as follows:

Notice how SYSTEM_TIME AS OF @Timestamp only needs to defined in one place and will be applied to both the Customer and Address tables within the view.

DECLARE @Timestamp DATETIME;

SELECT

    @Timestamp = [Timestamp]

FROM

  [Audit]

WHERE

  [Id] = @AuditId;

SELECT

    [Id],

    [Name],

    [Addresses]

FROM

    [v_Customer]

FOR

    SYSTEM_TIME AS OF @Timestamp

WHERE

    [Id] = @CustomerId;

Step 4: The REST API

Our sample system will expose it’s functionality using a REST API, which can be consumed by a front-end or some other service. We will concentrate on the query endpoints here, since that is where the interesting stuff happens. The controllers responsible for writes do as you would expect; they accept some data via a POST or PUT and update the data in the database via the domain model.

Our users can retrieve a customer and view their associated addresses via an HTTP GET to the following route:

[ApiController]

[Route("api")]

public class GetCustomerController : ControllerBase

{

    private readonly GetCustomerByIdQuery _query;

    public GetCustomerController(GetCustomerByIdQuery query)

    {

        _query = query;

    }

    [Route("customers/{customerId}")]

    [HttpGet]

    public async Task<IActionResult> Execute(int customerId, int? auditId)

    {

        var dto = await _query.Execute(customerId, auditId);

        var results = CreateCustomerResult(dto);

        return Ok(results);

    }

    private static GetCustomerResult CreateCustomerResult(CustomerDto dto)

    {

        var result = new GetCustomerResult

        {

            Name = dto.Name,

            Addresses = dto.Addresses.Select(CreateAddressResult).ToList(),

            Audits = dto.Audits.Select(CreateAuditResult).ToList()

        };

        return result;

    }

    private static GetCustomerAddressResult CreateAddressResult(AddressDto dto)

    {

        var result = new GetCustomerAddressResult

        {

            Id = dto.Id,

            City = dto.City,

            Code = dto.Code,

            Line = dto.Line,

            Province = dto.Province,

            Suburb = dto.Suburb

        };

        return result;

    }

    private static GetCustomerAuditResult CreateAuditResult(CustomerAuditDto dto)

    {

        var result = new GetCustomerAuditResult

        {

            Id = dto.Id,

            Messages = dto.Messages.ToList(),

            Timestamp = dto.Timestamp

        };

        return result;

    }

}

For versioning, the provided route will return a list of available customer versions and a separate route for retrieving the state of the customer for a specified version.

[ApiController]

[Route("api")]

public class GetCustomerVersionsController : ControllerBase

{

    private readonly GetVersionsQuery _query;

    public GetCustomerVersionsController(GetVersionsQuery query)

    {

        _query = query;

    }

    [Route("customers/{customerId}/versions")]

    [HttpGet]

    public async Task<IActionResult> Execute(int customerId)

    {

        var dtos = await _query.Execute(customerId);

        var results = dtos.Select(CreateGetCustomerVersionsResult);

        return Ok(results);

    }

    private GetCustomerVersionsResult CreateGetCustomerVersionsResult(CustomerVersionDto dto)

    {

        var result = new GetCustomerVersionsResult

        {

            Id = dto.Id,

            Timestamp = dto.Timestamp,

            Message = dto.Message

        };

        return result;

    }

}
[ApiController]

[Route("api")]

public class GetCustomerVersionController : ControllerBase

{

    private readonly GetCustomerByVersionIdQuery _query;

    public GetCustomerVersionController(GetCustomerByVersionIdQuery query)

    {

        _query = query;

    }

    [Route("customers/{customerId}/versions/{versionId}")]

    [HttpGet]

    public async Task<IActionResult> Execute(int customerId, int versionId)

    {

        var dto = await _query.Execute(customerId, versionId);

        var results = CreateCustomerResult(dto);

        return Ok(results);

    }

    public static GetCustomerVersionResult CreateCustomerResult(CustomerDto dto)

    {

        var result = new GetCustomerVersionResult

        {

            Name = dto.Name,

            Addresses = dto.Addresses.Select(CreateAddressResult).ToList(),

        };

        return result;

    }

    public static GetCustomerVersionAddressResult CreateAddressResult(AddressDto dto)

    {

        var result = new GetCustomerVersionAddressResult

        {

            Id = dto.Id,

            City = dto.City,

            Code = dto.Code,

            Line = dto.Line,

            Province = dto.Province,

            Suburb = dto.Suburb

        };

        return result;

    }

}

Wrapping up

I believe that SQL server temporal tables is a great option for solving this specific problem. It is transparent to the parts of your application which are not directly concerned with the technical aspects of point-in-time snapshots, while also providing simple and powerful point-in-time snapshot capabilities for the parts of your application which are.

You can probably get 90% of the way there by enabling temporal tables as an afterthought; but by thinking about these concepts when designing your domain model, there is potential for rich capabilities that will make your product owners and domain experts love you.

If you want to dig a bit deeper into the solution, check out the full code sample for this post here.


Ross Jones a software developer with over 10 years experience in enterprise software development. He has worked on numerous large software projects in finance, energy, logistics and more recently in the insurance industry with OUTsurance. He believes that solid software architecture is more important than ever in the world of cloud computing and spends his time honing these skills.

If you want to see more of his work, check out his Twitter, GitHub or blog.

Source-banner--1-

Cat eyes@2x

Subscribe to our blog

Don’t miss out on cool content. Every week we add new content to our blog, subscribe now.
